Feature

1.Fast response, 3ms only, which is much less than the average 20ms even 9 channels
act synchronously.
2.English,Chinese ,EsPanol,Deutsch,French,Italiano,Turkish,Russian&Korean menu can be
switched, full types specialize helicopter 8 swash plate modes, fixed wing 2 airfoils
3 rears, gliders 4 airfoils and 2 rears, multi-copter menu.
3.DSSS and FHSS spread-spectrum technology working synchronously, QPSK modulation
support excellent anti-interference performance.
4.Programmable mix control. Basic menu, advanced menu, graphic view for verities of
throttle and servo curve.
5.Support S-BUS, PPM and PWM signal.
6.Unique telemetry
Receiver integrates signal strength and voltage telemetry sensor.
Both R10DS and R9DS support extended engine voltage telemetry module PRM-01 and OSD
info telemetry module PRM-02. PRM-02 can feedback GPS, SPEED, voltage etc. on
AT9S/AT10 display when work with flight controller APM or PIX.
7.4096 section precision, 0.25us per section, servo anti-shake rudder.
8.Vibration alarm.
9.Support USB online upgrade, the upgrade firmware V1.3.2 add CAR and BOAT model type.
10.Four VR switches, three three-gear switches, four two-gear switches, a reset
trainer switch. Support multiple aerial control mode and PTZ control.

Specification

1.Size: AT9S- 183*100*193mm, R9DS- 41*23*14mm
2.Weight: 0.88kg
3.Frequency: 2.4GHz ISM band (2400MHz to 2483.5MHz)
4.Modulation mode: QPSK
5.Channel bandwidth: 5.0 MHz
6.Spread spectrum: DSSS&FHSS
7.Adjacent channel rejection: >38dbm
8.Transmitter power: <100mW (20dbm )
9.Operating current: <90mA
10.Operating voltage: 7.4~18.0V
11.Control distance: more than 900 meters ground, 1500 meters air, the actual control
distance depends on the flying environment
12.Channel: 9 channels
13.Compatible model: include all 120 degree and 90 degree swash-plate helicopter, all
fix wings, glider and multi-rotor
14.Simulator model: under the simulator model the transmitter action turn off, change
to power saving model
15.Screen: 2.8 inches 16 colorful screen, 240*320 pixels
16.Support receivers: R9DS(S-BUS&PWM), R10DS and R6DS

Note
If you do not receive CD, click here.
Click for New Manual for testing RSSI data.
Package

1x RadioLink AT9S Upgrade Transmitter
1x Mini R9DS
1x CD
