HGLRC Petrel 75Whoop 1.6" 75mm 1S PNP

Multirotors → Tinywhoops → BNF/ARF/RTF Whoops → HGLRC Petrel 75Whoop 1.6" 75mm 1S PNP

Product Name: Petrel 75Whoop brushless motor indoor FPV Drone Tinywhoop
Weight:33.4g (Weight without receiver)

Type:Petrel 75Whoop frame for indoor FPV Drone
Wheelbase:75mm
Propeller:40mm max
Frame size:98 * 98mm

Zeus5 AIO 1-2S flight controller
Input voltage:1-2S
FC firmware:BF HGLRC411 (HGLR)
ESC firmware:BL_S
Size:41.5*41.5mm

Zeus nano 350mW VTX
Output power:PIT/25/100/200/350mW
Input voltage:DC 5V
Size:16*16mm

Caddx ANT FPV camera
Image sensor:1/3 1000TVL CMOS
Input voltage:DC 5V
Size:14mm * 14mm

0802 22000KV brushless motor (1S version)
Input voltage:3.7V (1S)

0802 17000KV brushless motor (2S version)
Input voltage:7.4V (2S)

Recommended blade:40mm

Gemfan 1635-40mm 3-blades propeller
Quantity:4 CW & 4 CCW

Shipping list:
1x Petrel 75Whoop frame
1x Zeus5 AIO flight controller
1x Zeus nano 350mW VTX
1x Caddx ANT FPV camera
4x 0802 17000KV(2S version) / 22000KV(1S version) brushless motors
8x Gemfan 1635-40mm 3-blades propellers
1x IPEX mini copper tube antenna
1x TPU Battery fixing base
1x receiver (optional)

Recommended battery:
1S:300mAh-520mAh
